| Drilling performance | |
|---|---|
| Drilling performance steel (S235JR) | 15 mm |
| Continuous drilling performance steel (S235JR) | 12 mm |
Leírás és Paraméterek
| Dimensions and weights | |
|---|---|
| Column diameter | 60 mm |
| Length | 481 mm |
| Width/depth | 475 mm |
| Height | 980 mm |
| Weight approx. | 66 kg |
| Drilling table | |
|---|---|
| Workspace length | 290 mm |
| Workspace width | 290 mm |
| T-groove size | 10 mm |
| T-groove number | 2 |
| T-groove spacing | 100 mm |
| Min. distance chuck - drilling table | 98 mm |
| Max. distance chuck - drilling table | 375 mm |
| Electric Data | |
|---|---|
| Supply voltage | 230 V |
| Phase(s) | 1 Ph |
| Current type | AC |
| Mains frequency | 50 Hz |
| Machine base | |
|---|---|
| Min. distance chuck - machine base | 290 mm |
| Max. distance chuck - machine base | 355 mm |
| Work area length | 290 mm |
| Work area width | 280 mm |
| Machine base T-groove size | 14 mm |
| Machine base T-groove number | 2 |
| Machine base T-groove spacing | 100 mm |
| Motor(s) | |
|---|---|
| Spindle motor drive output | 0.85 kW |
| Speed range | |
|---|---|
| Speed range | 100 - 3000 min¯¹ |
| Speed control | electronically adjustable |
| Spindle | |
|---|---|
| Quill stroke | 60 mm |
| Spindle chuck | MT 2 |
| Reach | 235 mm |
| Standards and certifications | |
|---|---|
| Standard | DIN EN 55011 |
| EMV-Class | C2 |
| VPE | 1 |
